Neapco N3-1-1013-8
|
| |
|
Quantity in Basket:
None
Code: NEA-N3-1-1013-8
Price: $80.64
1 In Stock
|
| |
Companion Flange - Circular w/Straight Round Bore
1350 series, Ø1.500 Bore w/0.375 keyway
4xØ0.451 Holes, Ø2.750-F pilot
|
This part is a member of the following categories:
Search by Category * Companion Flanges * Circular with Straight Round Hole
| U-Joint Series |
|
1350 |
| Bore Diameter |
D |
1.500 |
| Keyway Size |
K |
0.375 |
| Flange Diameter |
A |
4.560 |
| Pilot Bore Diameter |
C |
2.750-F |
| Bolt Circle Diameter |
B |
3.750 |
Bolt Hole Diameter
(D = Drilled, T = Tapped) |
|
0.451-D |
| Number of Holes |
|
4.000 |
| Ground Hub Diameter |
E |
0.000 |
| Length Thru Bore |
F |
2.000 |
| Notes |
|
|
|
| |
|
