This part's status is Obsolete
.
|
Spicer 1-1-273
|
| |
|
Quantity in Basket:
None
Code: SPI-1-1-273
Price: $136.46
1 In Stock
|
| |
Companion Flange - Rectangular w/Straight Round Bore
1100 series, Ø1.250 Bore w/0.312 keyway
Ø2.250-F pilot, Ø1.875 hub diameter
|
The following parts may be used as alternates for this part:
Neapco N1-1-273
This part is a member of the following categories:
Search by Category * Companion Flanges * Rectangular with Straight Round Hole
| U-Joint Series |
|
1100 |
| Bore Diameter |
D |
1.250 |
| Keyway Size |
K |
0.312 |
| Flange Diameter |
A |
3.500 |
| Pilot Bore Diameter |
C |
2.250-F |
| Bolt Circle Diameter |
B |
2.750 |
Bolt Hole Diameter
(D = Drilled, T = Tapped) |
|
|
| Number of Holes |
|
4.000 |
| Ground Hub Diameter |
E |
1.875 |
| Length Thru Bore |
F |
1.500 |
| Flange Face to End of Hub |
G |
2.125 |
| Set Screw Thread |
|
0.375 |
Set Screw Location
Clock position viewed at Hub End and Keyway at 12 |
|
6 |
| Notes |
|
|
|
| |
|
