Spicer 2-4-1053-1
|
| |
|
Quantity in Basket:
None
Code: SPI-2-4-1053-1
Price: $324.35
1 In Stock
|
| |
End Yoke - Round Bore
1310 series, Ø1.375 Bore w/0.375 keyway, Ø2.125 hub diameter
|
| General Design Type |
|
Round Bore |
| U-Joint Series |
|
1310 |
| Bore Diameter |
P |
1.375 |
| SAE Keyway Width |
X |
0.375 |
| Hub Diameter |
R |
2.125 |
| Universal Joint Retaining Width |
E |
3.219 |
| Universal Joint Bearing Diameter |
D |
1.062 |
| Length Thru Bore |
Q |
1.125 |
| Centerline of Joint to End of Hub |
S |
2.594 |
| Set Screw Thread |
|
0.375 |
| Keyway Location |
|
12 |
Set Screw Location
Clock position viewed at Hub End and Keyway at 12 |
W |
6 |
| Joint Angle |
|
0.000 |
| Style |
|
Strap |
| Compatible U-Joint Kits |
|
SPI-5-153X,SPI-5-1310X,SPI-5-1310-1X |
| U-Bolt or Strap Assembly |
|
SPI-2-70-18X |
| Notes |
|
|
| Cast/Forged |
|
|
This part is used in the following assemblies or kits:
SPI-921256-1 - SHORT COUPLE
|
| |
|
