Spicer 3-2-439
|
| |
|
Quantity in Basket:
None
Code: SPI-3-2-439
Price: $127.83
2 In Stock
|
| |
Flange Yoke
1410 series, 4xØ.438 Holes on 3.750BC, Ø2.750M pilot
|
This part is a member of the following categories:
Search by Category * Flange Yokes * 1410
| Design Style |
|
Snap Ring Design |
| U-Joint Series |
|
1410 |
| Universal Joint Retaining Width |
|
4.438 |
| Universal Joint Bearing Diameter |
D |
1.188 |
| Flange Diameter |
A |
4.625 |
| Bolt Circle Diameter |
B |
3.750 |
| Horizontal Distance Between Holes (center to center) |
|
2.410 |
| Vertical Distance Between Holes (center to center) |
|
2.873 |
| Bolt Hole Diameter |
|
.438-D |
| Bolt Hole Quantity |
|
4.000 |
| Pilot Diameter (M-Male, F-Female) |
C |
2.750M |
| Centerline of Joint to Flange Face |
G |
1.938 |
| Compatible U-Joint Kits |
|
SPI-5-160X,SPI-5-1410X |
| |
|
30.000 |
| Notes |
|
|
| Cast/Forged |
|
Forged |
Known Idenfiying Marks (Casting/Forging numbers, etc.):
| | Mark | | Location |
| |
F3-2-251
| |
(may also be just 251) |
This part is used in the following assemblies or kits:
SPI-916625-1 - SHORT COUPLE
SPI-916625-1 - SHORT COUPLE
