Spicer 3-4-1481-1
	Quantity in Basket: None Code: SPI-3-4-1481-1 Price: $287.85
	Quantity:
End Yoke - Splined Bore 1410 series, Strap Style, Ø1.375x10 spline, Ø1.938 hub diameter

This part is a member of the following categories:

Search by Category * End Yokes * Splined Bore * 10 Splines * Ø1.375 - 10 Spline

U-Joint Series		1410
Spline Major Diameter		1.375
Spline Count		10.000
Spline Type		parallel
Spline Pressure Angle		n/a
Ground Hub Diameter	R	1.938
Length Thru Bore	Q	2.000
Centerline of Joint to End of Spline	S	3.688
Universal Joint Retaining Width	E	4.188
Universal Joint Bearing Diameter	D	1.188
Counterbore Depth		0.000
Joint Angle		30.000
Style		Strap
Compatible U-Joint Kits		SPI-5-160X,SPI-5-1410X
U-Bolt or Strap Assembly		SPI-3-70-28X
Bare Yoke part number (if assembly - included)
Slinger Part Number (if assembly - included)
Notes
Cast/Forged
