Spicer 3-4-343-1
|
| |
|
Quantity in Basket:
None
Code: SPI-3-4-343-1
Price: $122.06
2 In Stock
|
| |
End Yoke - Round Bore
1410 series, Ø1.250 Bore w/0.312 keyway, Ø2.250 hub diameter
|
This part is a member of the following categories:
Search by Category * End Yokes * Round Bore
| General Design Type |
|
Round Bore |
| U-Joint Series |
|
1410 |
| Bore Diameter |
P |
1.250 |
| SAE Keyway Width |
X |
0.312 |
| Hub Diameter |
R |
2.250 |
| Universal Joint Retaining Width |
E |
4.188 |
| Universal Joint Bearing Diameter |
D |
1.188 |
| Length Thru Bore |
Q |
2.000 |
| Centerline of Joint to End of Hub |
S |
3.688 |
| Set Screw Thread |
|
0.375 |
| Keyway Location |
|
12 |
Set Screw Location
Clock position viewed at Hub End and Keyway at 12 |
W |
6 |
| Joint Angle |
|
0.000 |
| Style |
|
Strap |
| Compatible U-Joint Kits |
|
SPI-5-160X,SPI-5-1410X |
| U-Bolt or Strap Assembly |
|
SPI-3-70-28X |
| Notes |
|
|
| Cast/Forged |
|
Cast |
