This part's status is Obsolete
SPI-55474 has been replaced by SPI-2017426.
*** Fits most 2005 and up Ford model Dana 60 applications with unitized hub bearings ***
|
Spicer 55474
|
| |
|
Quantity in Basket:
None
Code: SPI-55474
Price: $23.05
Obsolete
|
| |
|
SEAL, Outer Axleshaft
|
Typical 2005+ Ford Super Duty Dana 60 Front service parts:
;SPI-2005932 - Inner Seal (axle tube seal)
;SPI-2017426 - Outer Seal
;SPI-54983 - O-Ring
;SPI-47766 - Axleshaft thrust bushing
;SPI-700238-2X - Ball Joint Kit
;SPI-SPL55-3X (non-greasable) or SPI-SPL55-4X (greasable) - Knuckle U-Joint
;SPI-52148 - Inner axle seal (at differential)
;SPI-2002692 - Outer axleshaft
The following parts may be used as alternates for this part:
Dana/Spicer 2017426 -- Obsolete
National Oil Seal 710685
| Type |
|
|
| Shaft Diameter (ID) |
|
3.528 |
| Housing Diameter (OD) |
|
5.469 |
| Width |
|
0.654 |
| Comments |
|
|
This part is used in the following assemblies or kits:
SPI-53217 - Axleshaft - Outer
|
