Spicer 3-4-3061-1
	Quantity in Basket: None Code: SPI-3-4-3061-1 Price: $110.02 1 In Stock
	Quantity:
End Yoke - Splined Bore 1480 series, Strap Style, Ø1.750x10 spline, Ø2.625 hub diameter

This part is a member of the following categories:

Search by Category * End Yokes * Splined Bore * 10 Splines * Ø1.750 - 10 Spline

U-Joint Series		1480
Spline Major Diameter		1.750
Spline Count		10.000
Spline Type		parallel
Spline Pressure Angle		n/a
Ground Hub Diameter	R	2.625
Length Thru Bore	Q	2.250
Centerline of Joint to End of Spline	S	4.281
Universal Joint Retaining Width	E	4.188
Universal Joint Bearing Diameter	D	1.375
Counterbore Depth		0.000
Joint Angle		23.000
Style		Strap
Compatible U-Joint Kits		SPI-5-188X,SPI-SPL55X,SPI-SPL55-1X
U-Bolt or Strap Assembly		SPI-3-70-38X
Bare Yoke part number (if assembly - included)		SPI-3-4-3061-1
Slinger Part Number (if assembly - included)		SPI-230909
Notes		.250 deep spline chamfer
Cast/Forged

This part is used in the following assemblies or kits:

SPI-3-4-5791-1X - End Yoke Assy - Splined Bore
